3780 ELECTRIC ACTUATOR / MULTIPLE TURN 93

  • FEATURES
  • FAF3780 Electric Actuator is a control instrument maintains the automation feature in valve control through transferring the angular movement controlled by proportional gears obtained from electrical motor to the valve stem.
  • Can be used with butterfly, ball, gate and plug valve, which are equipped with gearbox.
  • Can be used with gate and knife gate valves without gearboxes.
  • Actuator connection dimensions are defined according to ISO5211 standard.
  • Actuator selection is made based on actuator type, torque requirements, stem number of turn and connection dimensions.
  • Can be operated with 380V/220V/110VAC or 110/24VDC power sources.
  • Divided into two as ON/OFF or proportional controlled.
  • Proportional control can be obtained with 4-20mA or 0-10 VDC signals.
  • Aluminum body is coated with fusion-bonded epoxy, high resistance to corrosion.
  • Manual operation on the actuator is possible incase of power source failure.
  • It is advised to receive support from FAF Valve technical staff while selecting actuators to be used with our valves.
